ALIZIA 352
Ultrasonic Wind Sensor
Main features
- Very low power consumption
- Corrosion resistant, IP65
- Measures speed from 0 to 60 m/s
- Measures wind direction from 0 to 360°
- Accurate and maintenance-free
ALIZIA 352 is a high precision ultrasonic wind sensor that combines the functions of an anemometer and a wind vane. The measurement principle of ALIZIA 352 is based on the propagation time of an ultrasonic wave between two transducers.
Wind speed/direction
Electrical features
Communication
Wind speed/direction
| Range | 0-60m/s | 0° to 360° |
| Unit | m/s | Degree |
| Accuracy | ± 2% @ 12 m/s | ± 2° @ 12 m/s |
| Starting threshold | 0.01m/s | |
| Resolution | 0.01 m/s | 1° |
| Type of available data | Instantaneous speed | Instantaneous direction |
Electrical features
| Input power supply | 5 to 30 Vdc |
| Typical power consumption | 5.5 mA @12 Vdc |
| Cable connector | CL1F1201 |
Communication
| Interface | RS-422 |
| Format | NMEA 0183 |
| Flow rate | 9600, 19200, 38400 ou 115200 bauds |
| Wind sampling frequency | 1 Hz, 2 Hz ou 4 Hz |
Options
SOLAR SUPPLY
Tropical solar power supply for ALIZIA 380
Main features
- Solar power supply for ALIZIA 380
- Crutch for easy tilting
- Allows the connection of the sensor
FB-10M
Frangible mast (wind measurement at 10 metres)
Main features
- Frangible
- Daytime signs
- Tilting for easy maintenance
